Tempat asal:
Cina
Nama merek:
Z&H
Nomor model:
67390-67322
| Nama Produk | Bantalan rol tirus buatan China berkualitas tinggi |
| Ukuran | 133.35*196.85*38.1 MM |
| Merek | Z&H |
| Jenis | Bantalan rol lancip satu baris, Bantalan rol tirus dua baris, Bantalan rol tirus empat baris, bantalan otomatis, Bantalan alat mesin, Bantalan konstruksi, Bantalan tugas berat, bantalan rol tirus, bantalan mesin pertanian. |
| bahan bantalan | bantalan baja Gcr15 |
| Bahan Kandang | Baja, Kuningan |
| Performa kecepatan tinggi | Bagus |
| Standar Kualitas | ISO9001: 2000 |
| Melayani | layanan OEM |
| Jangka waktu pembayaran | T/T,L/C |
| Aplikasi secara luas | Banyak digunakan dalam mesin umum, mobil, mesin pertanian dan sebagainya |
| Kemasan | tas tunggal + kotak tunggal + karton / sesuai permintaan Anda |
| Pasar | Eropa, Amerika, Timur Tengah, Asia, dll |
| Penamaan | Dimensi utama | Peringkat beban dasar | Peringkat kecepatan | ||||
| dinamis | statis | Kecepatan referensi | Membatasi kecepatan | ||||
| D | D | T | C | C0 | |||
| - | mm | kn | r/mnt | ||||
| 30319 | 95 | 200 | 50 | 330 | 390 | 2600 | 3400 |
| 33220 | 100 | 180 | 63 | 429 | 655 | 2400 | 3600 |
| 33022 | 110 | 170 | 47 | 281 | 500 | 2600 | 3600 |
| 33122 | 110 | 180 | 56 | 369 | 630 | 2600 | 3400 |
| 32322 | 110 | 240 | 85 | 627 | 830 | 1900 | 2800 |
| 32924 | 120 | 165 | 29 | 165 | 305 | 2600 | 3800 |
| 33024 | 120 | 180 | 48 | 292 | 540 | 2600 | 3400 |
| 32926 | 130 | 180 | 32 | 198 | 365 | 2400 | 3600 |
| 32928 | 140 | 190 | 32 | 205 | 390 | 2200 | 3400 |
| 33030 | 150 | 225 | 59 | 457 | 865 | 2000 | 2600 |
| 30230 | 150 | 270 | 49 | 429 | 560 | 1800 | 2400 |
| 32934 | 170 | 230 | 38 | 286 | 585 | 1900 | 2800 |
| 32936 | 180 | 250 | 45 | 352 | 735 | 1700 | 2600 |
| 32938 | 190 | 260 | 45 | 358 | 765 | 1600 | 2400 |
| 32940 | 200 | 280 | 51 | 473 | 950 | 1500 | 2200 |
| 32944 | 220 | 300 | 51 | 484 | 1000 | 1400 | 2000 |
| 32948 | 240 | 320 | 51 | 512 | 1080 | 1300 | 1900 |
| 32960 | 300 | 420 | 76 | 1050 | 2240 | 950 | 1400 |
| 32964 | 320 | 440 | 76 | 1080 | 2360 | 900 | 1300 |
| 332303 | 320 | 620 | 141 | 2810 | 4650 | 700 | 1000 |
| 32968 | 340 | 460 | 76 | 1080 | 2400 | 850 | 1300 |
| 32972 | 360 | 480 | 76 | 1120 | 2550 | 800 | 1200 |
| 332302 | 360 | 680 | 165 | 3690 | 6300 | 630 | 900 |
| 30302J2 | 15 | 42 | 14.25 | 22.4 | 20 | 13000 | 18000 |
| 30203J2 | 17 | 40 | 13.25 | 19 | 18.6 | 13000 | 18000 |
| 30303J2 | 17 | 47 | 15.25 | 28.1 | 25 | 12000 | 16000 |
| 32303J2/Q | 17 | 47 | 20.25 | 34.7 | 33.5 | 11000 | 16000 |
| 32004X/Q | 20 | 42 | 15 | 24.2 | 27 | 12000 | 16000 |
| 30204J2/Q | 20 | 47 | 15.25 | 27.5 | 28 | 11000 | 15000 |
| 30304J2/Q | 20 | 52 | 16.25 | 34.1 | 32.5 | 11000 | 14000 |
| 32304J2/Q | 20 | 52 | 22.25 | 44 | 45.5 | 10000 | 14000 |
| 320/22X | 22 | 44 | 15 | 25.1 | 29 | 11000 | 15000 |
| 32005X/Q | 25 | 47 | 15 | 27 | 32.5 | 11000 | 14000 |
| 30205J2/Q | 25 | 52 | 16.25 | 30.8 | 33.5 | 10000 | 13000 |
| 32205BJ2/Q | 25 | 52 | 19.25 | 35.8 | 44 | 9500 | 13000 |
| 33205/Q | 25 | 52 | 22 | 47.3 | 56 | 10000 | 13000 |
| 30305J2/Q | 25 | 62 | 18.25 | 44.6 | 43 | 9000 | 12000 |
| 31305J2 | 25 | 62 | 18.25 | 38 | 40 | 7500 | 11000 |
| 32305J2 | 25 | 62 | 25.25 | 60.5 | 63 | 8000 | 12000 |
| 320/28X/Q | 28 | 52 | 16 | 31.9 | 38 | 10000 | 13000 |
| 302/28J2 | 28 | 58 | 17.25 | 38 | 41.5 | 9000 | 12000 |
| 322/28BJ2/Q | 28 | 58 | 20.25 | 41.8 | 50 | 8500 | 12000 |
| 32006X/Q | 30 | 55 | 17 | 35.8 | 44 | 9000 | 12000 |
| 30206J2/Q | 30 | 62 | 17.25 | 40.2 | 44 | 8500 | 11000 |
| 32206BJ2/QCL7CVA606 | 30 | 62 | 21.25 | 49.5 | 58.5 | 8000 | 11000 |
| 32206J2/Q | 30 | 62 | 21.25 | 50.1 | 57 | 8500 | 11000 |
| 33206/Q | 30 | 62 | 25 | 64.4 | 76,5 | 7500 | 11000 |
| 30306J2/Q | 30 | 72 | 20,75 | 56.1 | 56 | 7500 | 10000 |
| 31306J2/Q | 30 | 72 | 20,75 | 47.3 | 50 | 6700 | 9500 |
| 32306J2/Q | 30 | 72 | 28.75 | 76,5 | 85 | 7000 | 10000 |
| JL26749F/710 | 32 | 53 | 14.5 | 27 | 35.5 | 9000 | 12000 |
| 320/32X/Q | 32 | 58 | 17 | 36.9 | 46,5 | 8500 | 11000 |
| 32007J2/Q | 35 | 62 | 18 | 37.4 | 49 | 8000 | 11000 |
| 32007X/Q | 35 | 62 | 18 | 42.9 | 54 | 8500 | 11000 |
| 30207J2/Q | 35 | 72 | 18.25 | 51.2 | 56 | 7000 | 9500 |
| 32207J2/Q | 35 | 72 | 24.25 | 66 | 78 | 7000 | 9500 |
| 33207/Q | 35 | 72 | 28 | 84.2 | 106 | 6300 | 9500 |
| 30307J2/Q | 35 | 80 | 22.75 | 72.1 | 73.5 | 6700 | 9000 |
| 31307J2/Q | 35 | 80 | 22.75 | 61.6 | 67 | 6000 | 8500 |
| 32307BJ2/Q | 35 | 80 | 32.75 | 93.5 | 114 | 6000 | 8500 |
| 32307J2/Q | 35 | 80 | 32.75 | 95.2 | 106 | 6300 | 9000 |
| 32307/37BJ2/Q | 37 | 80 | 32.75 | 93.5 | 114 | 6000 | 8500 |
| JL69345F/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| JL69349A/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| JL69349X/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| JL69349/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| 32008/38X/Q | 38 | 68 | 19 | 52.8 | 71 | 7000 | 9500 |
| 3490/3420/QCL7CVQ492 | 38.1 | 79 | 29.37 | 91.3 | 110 | 6700 | 9500 |
| 32008X/Q | 40 | 68 | 19 | 52.8 | 71 | 7000 | 9500 |
| 32008XTN9/Q | 40 | 68 | 19 | 52.8 | 71 | 7000 | 9500 |
| 33108/Q | 40 | 75 | 26 | 79.2 | 104 | 6700 | 9000 |
| 30208J2/Q | 40 | 80 | 19.75 | 61.6 | 68 | 6300 | 8500 |
| 32208J2/Q | 40 | 80 | 24,75 | 74.8 | 86,5 | 6300 | 8500 |
| 33208/QCL7C | 40 | 80 | 32 | 105 | 132 | 5600 | 8500 |
| T2EE040/QVB134 | 40 | 85 | 33 | 121 | 150 | 6000 | 9000 |
| 30308J2/Q | 40 | 90 | 25.25 | 85.8 | 95 | 6000 | 8000 |
1 .Kemasan kotak tunggal, lalu di karton lalu di Pallet.
2 .Kemasan standar ekspor.
3 .Sesuai permintaan pelanggan.
1. Anda harus membayar di muka
2. Anda dapat menggunakan serikat barat
3.L/C pada pandangan
4.30% T/T di muka.70% terhadap salinan B/L
1. Bantalan rol silinder
2. Bantalan bola dorong
3. Bantalan rol dorong
4. Bantalan rol tirus
5. Bantalan rol bulat
6.Self-aligning ball bearing
7. Bantalan bola kontak sudut
8. Bantalan sendi
